Marshall CV366 Compact 3GSDI/HDMI Genlock Broadcast Camera

CV366 Compact 3GSDI/HDMI Genlock Broadcast Camera

$499.99
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

The Marshall CV366 Compact HD Camera with Genlock Sync features. Built around an impressive 1/1.8" Sony global sensor with 25% larger pixels and flexible CS lens mount (lens sold separately) make this the most capable POV camera in the compact camera lineup.

Tri-level sync allows multiple cameras to be plugged into HD workflows already in sync (genlock) which allows for seamless transitions between cameras with minimal amount of delay. Tri-level runs at higher frequency which makes the HD60 signal sync more accurate and more seamless.

Larger physical pixel sizes allow for greater accuracy of color and clarity even in low-light applications. The CV568 utilizes a Sony Exmor 1/1.8" sensor with larger physical pixels to deliver step-up broadcast quality images from a miniature camera size.

Durable, Flexible, Powerful
Marshall Compact Cameras are cut from individual aluminum alloy blocks, designed with rear I/O connector protection, solid 1/4"-20 mount type, and flexible interchangeable lenses. Ability to remotely adjust and match a POV camera from a control room that is installed hundreds or thousands of feet away is a powerful tool and comes standard with every Marshall Camera.

Features:

  • Color Matrix to be offered as firmware update (coming soon)
  • Microphone/Line Level input with 2.5V Mic bias
  • Image Mirror/Flip, Digital Zoom, Digital Image Stabilizer
  • Low Light sensitivity (0.05 Lux) with ability to capture IR wavelengths
  • 3.2MP with 25% larger physical pixel size
  • Simultaneous HDMI & 3GSDI outputs


Specifications:

  • Global Sensor: Sony 1/1.8" Exmor
  • SMPTE 424M (2.97Gbps) - 3GSDI:
    1920x1080p @ 50, 59.94, 60fps
  • SMPTE 292M (1.485Gbps) - HDSDI:
  • 1920x1080p @ 23.97, 24, 25, 29.97, 30fps
    1920x1080i @ 50, 59.94, 60fps
    1280x720p @ 50, 59.94, 60fps
  • Environmental: -10°C ~ 50°C
  • Power Consumption: 6W

Applications:


Broadcast
Production
Sports
Racing
Newscast
Weathercast
Live Events
Aerospace
House of Worship
Courtroom
Government
Education
eSports
Nature
Live Concert
Podcast
Studio
Stage
Science and Technology
